SIEMENS  6ED1 052-1FB00-0BA6  LOGIC MODULE, 8I/P, 4O/P, 230V

SIEMENS 6ED1 052-1FB00-0BA6

Image is for illustrative purposes only. Please refer to product description.

Additional images

  • Manufacturer:
  • Order Code: 1657153
  • Manufacturer Part No 6ED1 052-1FB00-0BA6

Product Overview

The 6ED1 052-1FB00-0BA6 from Siemens is LOGO! 230RC logic display module. It provides menu control, optional integrated control and display. This module can be expandable with additional 230VAC/VDC modules.
  • Rated input voltage is 115VDC / 230VDC
  • Relay output current 3A (inductive) 10A (resistive) load
  • 8 digital input, 4 relay digital output
  • 200 memory blocks
  • IP20 degree of protection
  • UL, CSA, FM, IEC, VDE approved
  • Dimension is 72mm x 90mm x 55mm (WxHxD)
  • Ambient operating temperature is 0°C to 55°C
  • 35mm DIN rail mountable
  • Radio interference suppression according to EN55011, Limit value of Class B


Automation & Process Control; Industrial
Back to top

Product Specifications, Documents & More

  • Approval Bodies: CSA, FM, IEC, UL, VDE
  • External Depth: 55mm
  • External Length / Height: 90mm
  • External Width: 72mm
  • IP / NEMA Rating: IP20
  • Meter Display Type: LCD
  • Mounting Type: DIN Rail
  • No. of Analogue Inputs: -
  • No. of Analogue Outputs: 2
  • No. of Digital Inputs: 8
  • No. of Digital Outputs: 4
  • Operating Temperature Max: +55°C
  • Operating Temperature Min: 0°C
  • SVHC: To Be Advised
  • Supply Voltage Max: 230V
  • Supply Voltage Min: 115V

Find similar products  grouped by common attribute


Check stock and lead times
  • 5 will be available for delivery on Mar 20, 2016
  • 5 will be available for delivery on Apr 6, 2016
  • 15 will be available for delivery on Apr 8, 2016
  • More stock available week commencing 4/11/16

Contact me when back in stock


  • 2080225 - LOGIC MODULE, 8I/P, 4O/P, 230V

Price for: Each 1

Minimum order quantity: 1

Order multiple quantity: 1

Price: US$152.646 US$152.646



Quantity List Price
1+ US$152.646

Legislation and Environmental

  • Country of Origin: China

    Country in which last significant manufacturing process was carried out

  • RoHS Compliant: Yes
      RoHS Certificate of Compliance
  • Tariff No: 85044090
  • Weight (kg): .212
