Farnell offers charging coils for wireless power transfer applications requiring reliable and efficient energy transmission. These components are designed to support wireless charging solutions across consumer, industrial and commercial electronic devices.

Charging coils use inductive coupling to transfer power without direct electrical connections. Available in various dimensions, inductance values and power capabilities, selection considerations include charging standard compatibility, coil size, operating frequency and power transfer requirements.

Applications:

Wireless chargers
Mobile devices
Wearable electronics
Medical devices
Industrial equipment
Consumer electronics

Manufacturer Part No	Order Code	Manufacturer / Description	Price For	Price (ex VAT)	Product Range	Inductance	Inductance Tolerance	DC Resistance Max	No. of Coils	No. of Layers	Saturation Current (Isat)	Self Resonant Frequency	Quality Factor	AC Current Rating	Product Length	Product Width	Product Height	Inductor Mounting	Operating Temperature Min	Operating Temperature Max

IWTX5555DEEB100KF1	3263661 Data Sheet RoHS Date/Lot Code	VISHAY Charging Coil IWTX Series 10 µH ± 10% 0.08 ohm 1 Coil 1 Layer	Each	1+US$3.270 10+US$2.841 50+US$2.693 100+US$2.358 200+US$2.224 More Pricing...	IWTX Series	10µH	± 10%	0.08ohm	1 Coil	1 Layer	-	-	99@100kHz	-	55mm	55mm	4.5mm	Board Mount	-40°C	85°C
IWAS3010AZEB130KF1	3263651 Data Sheet RoHS Date/Lot Code	VISHAY Charging Coil IWAS Series 13 µH ± 10% 0.78 ohm 1 Coil 1 Layer	Each	1+US$2.559 50+US$1.983 100+US$1.889 250+US$1.621 500+US$1.514 More Pricing...	IWAS Series	13µH	± 10%	0.78ohm	1 Coil	1 Layer	-	-	11@100kHz	-	10mm	30mm	1mm	Board Mount	-40°C	85°C
IWTX5050FEEB100KF1	3263658 Data Sheet RoHS	VISHAY Charging Coil IWTX Series 10 µH ± 10% 0.0297 ohm 1 Coil 2 Layers	Each	1+US$4.797 5+US$4.462 10+US$4.114 25+US$3.591 50+US$3.417 More Pricing...	IWTX Series	10µH	± 10%	0.0297ohm	1 Coil	2 Layers	-	-	200@100kHz	-	50mm	50mm	6.5mm	Board Mount	-40°C	85°C
IWTX47R0DAEB6R3JF1	3364904 Data Sheet RoHS	VISHAY Charging Coil IWTX Series 6.3 µH ± 5% 0.04 ohm 1 Coil 1 Layer	Each	1+US$5.333 10+US$4.476 25+US$4.248 50+US$3.712 100+US$3.471 More Pricing...	IWTX Series	6.3µH	± 5%	0.04ohm	1 Coil	1 Layer	22A	-	190@200kHz	7A	-	-	4.2mm	Board Mount	-40°C	105°C
IWTX4646DCEB240JF1	3364903 Data Sheet RoHS Date/Lot Code	VISHAY Charging Coil IWTX Series 24 µH ± 5% 0.075 ohm 1 Coil 2 Layers	Each	1+US$6.968 10+US$5.775 25+US$5.481 50+US$4.784 100+US$4.502 More Pricing...	IWTX Series	24µH	± 5%	0.075ohm	1 Coil	2 Layers	20A	-	185@200kHz	-	46mm	46mm	5.26mm	Board Mount	-40°C	105°C
146179-8021	2913968 Data Sheet RoHS	MOLEX Charging Coil PowerLife 146179 Series 4 µH ± 2% 0.235 ohm 1 Coil 1 Layer	Each	1+US$9.367 10+US$7.745 20+US$7.370	PowerLife 146179 Series	4µH	± 2%	0.235ohm	1 Coil	1 Layer	-	-	115@6.78MHz	-	-	-	0.685mm	Board Mount	-	-
146179-0001	3862519 Data Sheet	MOLEX Charging Coil PowerLife 146179 Series 17.3 µH ± 2% 0.45 ohm 1 Coil 1 Layer	Each	5+US$4.811	PowerLife 146179 Series	17.3µH	± 2%	0.45ohm	1 Coil	1 Layer	-	-	-	-	43mm	50mm	0.63mm	Board Mount	-	-
760308103204	2400024 Data Sheet RoHS Date/Lot Code	WURTH ELEKTRONIK Charging Coil Wireless WE-WPCC Series 16.7 µH ± 10% 0.43 ohm 1 Coil 1 Layer	Each	1+US$8.013 3+US$7.517 5+US$6.955 10+US$6.579 20+US$6.419 More Pricing...	WE-WPCC Series	16.7µH	± 10%	0.43ohm	1 Coil	1 Layer	4A	11MHz	32@125kHz	-	30.5mm	38.5mm	0.85mm	Board Mount	-20°C	105°C
WR483245-15F5-G	2377528 Data Sheet RoHS Date/Lot Code	TDK Charging Coil Wireless WR Series 13 µH 0.2 ohm 1 Coil 1 Layer	Each	1+US$5.119 5+US$4.583 10+US$4.047 25+US$3.806 50+US$3.591 More Pricing...	WR Series	13µH	-	0.2ohm	1 Coil	1 Layer	-	-	-	-	32.5mm	48.5mm	1mm	Board Mount	-30°C	70°C
WR303050-15F5-G	2377529 Data Sheet RoHS Date/Lot Code	TDK Charging Coil Wireless WR Series 12.3 µH 0.41 ohm 1 Coil 1 Layer	Each	1+US$3.296 10+US$2.519 25+US$2.305 50+US$2.224 100+US$2.144 More Pricing...	WR Series	12.3µH	-	0.41ohm	1 Coil	1 Layer	-	-	-	-	30mm	30.4mm	0.92mm	Board Mount	-30°C	70°C
WR444030-16F3-G	2377530 Data Sheet RoHS Date/Lot Code	TDK Charging Coil Wireless WR Series 19 µH 0.7 ohm 1 Coil 1 Layer	Each	1+US$5.373 10+US$4.167 25+US$3.926 50+US$3.739 100+US$3.538 More Pricing...	WR Series	19µH	-	0.7ohm	1 Coil	1 Layer	-	-	-	-	44mm	40mm	0.62mm	Board Mount	-30°C	70°C
760308103205	2467268 Data Sheet RoHS Date/Lot Code	WURTH ELEKTRONIK Charging Coil Wireless WE-WPCC Series 11 µH ± 10% 0.2 ohm 1 Coil 1 Layer	Each	1+US$8.321 5+US$7.826 10+US$7.343 20+US$6.847 40+US$6.365 More Pricing...	WE-WPCC Series	11µH	± 10%	0.2ohm	1 Coil	1 Layer	-	16MHz	30@125kHz	-	26.5mm	34mm	0.89mm	Board Mount	-20°C	105°C
760308103206	2467269 Data Sheet RoHS Date/Lot Code	WURTH ELEKTRONIK Charging Coil Wireless WE-WPCC Series 7.5 µH ± 10% 0.38 ohm 1 Coil 1 Layer	Each	1+US$10.037 5+US$9.460 10+US$8.884 20+US$8.295 40+US$7.718 More Pricing...	WE-WPCC Series	7.5µH	± 10%	0.38ohm	1 Coil	1 Layer	-	23MHz	16@125kHz	-	15.7mm	28.9mm	0.76mm	Board Mount	-20°C	105°C
WT151512-22F2-ID	2790521 Data Sheet RoHS Date/Lot Code	TDK Charging Coil Transmitter WT Series 6.8 µH ± 5% 0.18 ohm 1 Coil 2 Layers	Each	1+US$4.181 10+US$3.497 50+US$3.189 200+US$2.573 400+US$2.332 More Pricing...	WT Series	6.8µH	± 5%	0.18ohm	1 Coil	2 Layers	-	-	-	-	-	-	2.42mm	Board Mount	-30°C	70°C
760308111	2291720 Data Sheet RoHS Date/Lot Code	WURTH ELEKTRONIK Charging Coil Wireless WE-WPCC Series 6.3 µH ± 10% 0.024 ohm 1 Coil 2 Layers	Each	1+US$16.670 10+US$14.593 20+US$13.842	WE-WPCC Series	6.3µH	± 10%	0.024ohm	1 Coil	2 Layers	16A	20MHz	80@125kHz	-	53.3mm	53.3mm	6mm	Board Mount	-20°C	105°C
760308101219	2543256 Data Sheet RoHS Date/Lot Code	WURTH ELEKTRONIK Charging Coil Wireless WE-WPCC Series 11.8 µH ± 10% 0.75 ohm 1 Coil 1 Layer	Each	1+US$7.960 3+US$7.651 5+US$7.450 10+US$7.236 20+US$6.727 More Pricing...	WE-WPCC Series	11.8µH	± 10%	0.75ohm	1 Coil	1 Layer	-	22MHz	13@125kHz	-	-	-	0.6mm	Board Mount	-20°C	105°C
SWC4242KB120-100	2452018 Data Sheet RoHS Date/Lot Code	LAIRD Charging Coil Wireless SWC Series 12.5 µH ± 10% 0.24 ohm 1 Coil 1 Layer	Each	1+US$8.321 10+US$6.995 50+US$6.151 100+US$5.816 200+US$5.320 More Pricing...	SWC Series	12.5µH	± 10%	0.24ohm	1 Coil	1 Layer	-	-	20@100kHz	-	42mm	42mm	0.7mm	Board Mount	-40°C	85°C
760308101208	2467264 Data Sheet RoHS	WURTH ELEKTRONIK Charging Coil Wireless WE-WPCC Series 13 µH ± 10% 0.5 ohm 1 Coil 3 Layers	Each	1+US$10.680 10+US$10.385 50+US$10.090 100+US$8.536 200+US$7.960 More Pricing...	WE-WPCC Series	13µH	± 10%	0.5ohm	1 Coil	3 Layers	-	26MHz	17@125kHz	-	-	-	1.68mm	Board Mount	-20°C	105°C
760308105309	2965274 Data Sheet RoHS Date/Lot Code	WURTH ELEKTRONIK Charging Coil WE-WPCC Series 10 µH ± 10% 0.45 ohm 1 Coil 1 Layer	Each	1+US$9.675 5+US$8.375 10+US$7.410 20+US$7.236 40+US$7.048 More Pricing...	WE-WPCC Series	10µH	± 10%	0.45ohm	1 Coil	1 Layer	-	18.5MHz	19@125kHz	-	-	-	0.49mm	Board Mount	-20°C	105°C
IWTX50R0CZEB6R3KF1	3263659 Data Sheet RoHS Date/Lot Code	VISHAY Charging Coil IWTX Series 6.3 µH ± 10% 0.045 ohm 1 Coil 1 Layer	Each	1+US$2.157 10+US$1.769 50+US$1.554 200+US$1.487 400+US$1.394 More Pricing...	IWTX Series	6.3µH	± 10%	0.045ohm	1 Coil	1 Layer	-	-	120@100kHz	-	-	-	3mm	Board Mount	-40°C	85°C
WR301025-19M8-G	2790529 Data Sheet RoHS Date/Lot Code	TDK Charging Coil Receiver WR Series 12.8 µH 1.27 ohm 1 Coil 2 Layers	Each	1+US$2.104 50+US$2.010 100+US$1.903 250+US$1.809 500+US$1.702 More Pricing...	WR Series	12.8µH	-	1.27ohm	1 Coil	2 Layers	-	-	-	-	10mm	30mm	0.52mm	Board Mount	-30°C	70°C
WR444025-17M6-G	2790531 Data Sheet RoHS Date/Lot Code	TDK Charging Coil Receiver WR Series 16.7 µH 0.65 ohm 1 Coil 1 Layer	Each	1+US$6.311 50+US$5.333 100+US$4.998 250+US$4.703 500+US$4.502 More Pricing...	WR Series	16.7µH	-	0.65ohm	1 Coil	1 Layer	-	-	-	-	44mm	40mm	0.52mm	Board Mount	-30°C	70°C
WT202012-15F2-ID	2790522 Data Sheet RoHS Date/Lot Code	TDK Charging Coil Transmitter WT Series 6.2 µH ± 5% 0.095 ohm 1 Coil 2 Layers	Each	1+US$2.600 10+US$2.546 50+US$2.506 100+US$2.452 200+US$2.412 More Pricing...	WT Series	6.2µH	± 5%	0.095ohm	1 Coil	2 Layers	-	-	-	-	-	-	2.84mm	Board Mount	-30°C	70°C
IWAS3827ABEB110JF1	3364898 Data Sheet RoHS Date/Lot Code	VISHAY Charging Coil IWAS Series 11 µH ± 5% 0.185 ohm 1 Coil 1 Layer	Each	1+US$4.663 10+US$4.074 50+US$3.672 100+US$3.444 200+US$3.216 More Pricing...	IWAS Series	11µH	± 5%	0.185ohm	1 Coil	1 Layer	-	-	30@200kHz	-	26.65mm	38.1mm	1.7mm	Board Mount	-40°C	105°C
760308201	2114372 Data Sheet RoHS Date/Lot Code	WURTH ELEKTRONIK Charging Coil Wireless WE-WPCC Series 10 µH ± 5% 0.2 ohm 1 Coil 1 Layer	Each	1+US$20.783 3+US$18.894 5+US$17.688 10+US$17.165 20+US$16.629 More Pricing...	WE-WPCC Series	10µH	± 5%	0.2ohm	1 Coil	1 Layer	8A	15MHz	50@125kHz	-	37mm	37mm	1.8mm	Board Mount	-20°C	105°C
